What Are Stainless Steel 347 Sheets & Plates?
Global Steel is a name to be considered in the market. As a well-known Stainless Steel 347 Sheets & Plates manufacturer, supplier, stockist, and exporter, we have made a name in delivering high-grade material that adheres to the high standards of numerous sectors worldwide. Our Stainless Steel 347H range offers unmatched strength, high corrosion resistance, and perfect compatibility in applications where stress and high-temperature resistance are crucial.
Table of Content
- SS 347H Sheets & Plates Specification Chart
- SS 347H Sheets & Plates Chemical Composition
- SS 347H Sheets & Plates Mechanical Properties
- Weight Chart Of SS 347H Sheets & Plates
- Stainless Steel 347 Sheets & Plates Price Per Kg
- People Also Search
- Application Of Industries
- Types Of SS 347H Sheets & Plates
Stainless Steel 347 Sheets & Plates, Stainless Steel 347 Sheets & Plates Manufacturers, Stainless Steel 347 Sheets & Plates Suppliers, Stainless Steel 347 Sheets & Plates Stockists, Stainless Steel 347 Sheets & Plates Exporters
Stainless Steel 347H is columbium (niobium) stabilized austenitic stainless steel with high corrosion resistance in the intergranular region. It possesses high applicability in high-temperature exposure and aggressive environments applications. 347H stainless steel resists carbide precipitation in high-temperature applications and thus maintains its structure in contrast to 304 stainless steel and finds its application in aerospace, chemical processing, power generation, and food processing industries.
Global Steel Stainless Steel 347H plates and sheets have been widely acclaimed due to their high mechanical and physical properties. The sheets and plates contain high creep strength, high tensile strength, and improved weldability. The sheets and plates are used in heat exchangers, tubes in boilers, exhaust systems, and aircraft components and provide strength and reliability in aggressive conditions. Their stress corrosion cracking resistance gives long-lasting performance in aggressive conditions as well.
Stainless Steel 347 Sheets & Plates Manufacturers in India, Stainless Steel 347 Sheets & Plates Suppliers in India, Stainless Steel 347 Sheets & Plates Stockists in India, Stainless Steel 347 Sheets & Plates Exporters in India
Stainless Steel 347H has made it a popular material in numerous industries. The chemical and petrochemical industries rely on it to process equipment that can withstand high-temperature and corrosive environments. It is used in the aerospace industry in the form of engine components and high-temperature structures. The food and beverage industry uses its capacity to resist contamination and withstand sterilization processes.
Being a well-known name in the stainless steel industry, Global Steel takes pride in supplying high-grade Stainless Steel 347H sheets and plates. We stand apart from others due to our quality commitment, precision manufacturing, and client satisfaction. For the finest quality Stainless Steel 347H sheets and plates, count on Global Steel – your trusted partner in high-grade stainless steel supplies. Contact us now and avail the best prices and hassle-free service.
Stainless Steel 347 Sheets & Plates Manufacturers in Mumbai, Stainless Steel 347 Sheets & Plates Suppliers in Mumbai, Stainless Steel 347 Sheets & Plates Stockists in Mumbai, Stainless Steel 347 Sheets & Plates Exporters in Mumbai
Stainless Steel 347 Sheets & Plates Specifications
| Standard | ASTM A240, ASME SA240 |
|---|---|
| Thickness | 0.1mm to 12 mm Thk |
| Sheet/Plate Size | 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm |
| Surface | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sandblast, Brush, etching. |
| Finish | Hot rolled (HR), Cold rolled (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated), Galvanized etc. |
Chemical Composition for Stainless Steel 347 Sheets & Plates
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
|---|---|---|---|---|---|---|---|---|---|
| SS 347H | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 – 20 | – | 8 – 11 | - |
Mechanical properties of Stainless Steel 347 Sheets & Plates
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Weight Chart Of Stainless Steel 347 Sheets & Plates
| Plate Thickness (mm) | Weight (kg/m) | kg/meter (width 1200mm) | kg/meter (width 1500mm) | kg/meter (width 1800mm) | kg/meter (width 2400mm) |
|---|---|---|---|---|---|
| 3 | 23.55 | 28.3 | 35.3 | 42.4 | 56.5 |
| 4 | 31.4 | 37.7 | 47.1 | 56.5 | 75.4 |
| 5 | 39.25 | 47.1 | 58.9 | 70.7 | 94.2 |
| 6 | 47.1 | 56.5 | 70.7 | 84.8 | 113 |
| 8 | 62.8 | 75.4 | 94.2 | 113 | 150.7 |
| 10 | 78.5 | 94 | 118 | 141 | 188 |
| 12 | 94.2 | 113 | 141 | 170 | 226 |
| 16 | 125.6 | 151 | 188 | 226 | 301 |
| 20 | 157 | 188 | 236 | 283 | 377 |
| 22 | 172.7 | 207 | 259 | 311 | 415 |
| 25 | 196.25 | 236 | 294 | 353 | 471 |
| 28 | 219.8 | 264 | 330 | 396 | 528 |
| 32 | 251.2 | 301 | 377 | 452 | 603 |
| 36 | 282.6 | 339 | 424 | 509 | 678 |
| 40 | 314 | 377 | 471 | 565 | 754 |
| 45 | 353.25 | 424 | 530 | 636 | 848 |
| 50 | 392.5 | 471 | 589 | 707 | 942 |
| 55 | 431.75 | 518 | 648 | 777 | 1036 |
| 60 | 471 | 565 | 707 | 848 | 1130 |
| 65 | 510 | 612 | 765 | 918 | 1224 |
| 70 | 549.5 | 659 | 824 | 989 | 1319 |
| 75 | 588.75 | 707 | 883 | 1060 | 1413 |
| 80 | 628 | 754 | 942 | 1130 | 1507 |
| 90 | 706.5 | 848 | 1060 | 1272 | 1696 |
| 100 | 785 | 942 | 1178 | 1413 | 1884 |
Stainless Steel 347 Sheets & Plates Price Per Kg
| Material | Price In INR | Price In USD |
|---|---|---|
| Stainless Steel 347H | ₹ 200 - Per kg | $ 2.5 - Per kg |
