What Are Incoloy 825 Sheets & Plates?
Global Steel is a reputed manufacturer, supplier, stockist, and exporter of high-quality Incoloy 825 Sheets & Plates, noted for their corrosion resistance and high tensile strength. As a company with many years of experience as an industry leader, we are dedicated to supplying high-class quality Incoloy 825 products as solutions to diverse industrial applications.
Table of Content
- Incoloy 825 Sheets & Plates Specification Chart
- Incoloy 825 Sheets & Plates Chemical Composition
- Incoloy 825 Sheets & Plates Mechanical Properties
- Weight Chart Of Incoloy 825 Sheets & Plates
- Incoloy 825 Sheets & Plates Price Per Kg
- People Also Search
- Application Of Industries
- Types Of Incoloy 825 Sheets & Plates
Incoloy 825 Sheets & Plates, Incoloy 825 Sheets & Plates Manufacturers, Incoloy 825 Sheets & Plates Suppliers, Incoloy 825 Sheets & Plates Stockists, Incoloy 825 Sheets & Plates Exporters
Our Incoloy 825 Sheets & Plates are manufactured with high-grade raw materials and advanced technology, guaranteeing high mechanical properties and durability.The composition of Incoloy 825, a nickel-iron-chromium alloy with added copper, titanium, and molybdenum, offers superior resistance to reducing as well as oxidizing acids, especially sulfuric and phosphoric acids. The composition allows our Incoloy 825 Sheets & Plates to excel in demanding chemical conditions, with great performance in pressure vessels, heat exchangers, pollution-control equipment, and piping systems.
At Global Steel, we are quality-conscious and put our products through thorough testing and quality inspection to provide assurance of compliance with international specifications like ASTM, ASME, and other industry standards.
Incoloy 825 Sheets & Plates Manufacturers in India, Incoloy 825 Sheets & Plates Suppliers in India, Incoloy 825 Sheets & Plates Stockists in India, Incoloy 825 Sheets & Plates Exporters in India
The flawless blend of strength, toughness, and corrosion resistance in adverse environments makes our Incoloy 825 Sheets & Plates the first choice for mission-critical applications. Global Steel always works towards improving its processing methods and embracing cutting-edge technologies to deliver innovative solutions to its clients. Be it standard or custom-made Incoloy 825 Sheets & Plates, we guarantee maximum quality, dependability, and service.
Choose Global Steel for your requirements of Incoloy 825 and enjoy world-class products supported by technical expertise and industry-leading guidance. To know more or request a quotation, contact us today and let us assist you in discovering the ultimate solution for your industrial needs.
Incoloy 825 Sheets & Plates Manufacturers in Mumbai, Incoloy 825 Sheets & Plates Suppliers in Mumbai, Incoloy 825 Sheets & Plates Stockists in Mumbai, Incoloy 825 Sheets & Plates Exporters in Mumbai
Incoloy 825 Sheets & Plates Specifications
| Specifications | ASTM B168, B443, B670 / ASME SB168, SB443, SB670 |
|---|---|
| Dimension Standard | JIS, AISI, ASTM, GB, DIN, EN, etc |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Thickness | 0.3 mm to 120 mm |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Surface Finishing | Hot rolled plate (HR), Cold rolled sheet (CR),2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, Chequered, embossed, hair line, sand blast, Brush, etching, SATIN (Met with Plastic Coated) etc. |
Chemical Composition for Incoloy 825 Sheets & Plates
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
|---|---|---|---|---|---|---|---|---|---|
| Incoloy 825 | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 – 20 | - | 8 – 11 | - |
Mechanical properties of Incoloy 825 Sheets & Plates
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Weight Chart Of Incoloy 825 Sheets & Plates
| Plate Thickness (mm) | Weight (kg/m) | kg/meter (width 1200mm) | kg/meter (width 1500mm) | kg/meter (width 1800mm) | kg/meter (width 2400mm) |
|---|---|---|---|---|---|
| 3 | 23.55 | 28.3 | 35.3 | 42.4 | 56.5 |
| 4 | 31.4 | 37.7 | 47.1 | 56.5 | 75.4 |
| 5 | 39.25 | 47.1 | 58.9 | 70.7 | 94.2 |
| 6 | 47.1 | 56.5 | 70.7 | 84.8 | 113 |
| 8 | 62.8 | 75.4 | 94.2 | 113 | 150.7 |
| 10 | 78.5 | 94 | 118 | 141 | 188 |
| 12 | 94.2 | 113 | 141 | 170 | 226 |
| 16 | 125.6 | 151 | 188 | 226 | 301 |
| 20 | 157 | 188 | 236 | 283 | 377 |
| 22 | 172.7 | 207 | 259 | 311 | 415 |
| 25 | 196.25 | 236 | 294 | 353 | 471 |
| 28 | 219.8 | 264 | 330 | 396 | 528 |
| 32 | 251.2 | 301 | 377 | 452 | 603 |
| 36 | 282.6 | 339 | 424 | 509 | 678 |
| 40 | 314 | 377 | 471 | 565 | 754 |
| 45 | 353.25 | 424 | 530 | 636 | 848 |
| 50 | 392.5 | 471 | 589 | 707 | 942 |
| 55 | 431.75 | 518 | 648 | 777 | 1036 |
| 60 | 471 | 565 | 707 | 848 | 1130 |
| 65 | 510 | 612 | 765 | 918 | 1224 |
| 70 | 549.5 | 659 | 824 | 989 | 1319 |
| 75 | 588.75 | 707 | 883 | 1060 | 1413 |
| 80 | 628 | 754 | 942 | 1130 | 1507 |
| 90 | 706.5 | 848 | 1060 | 1272 | 1696 |
| 100 | 785 | 942 | 1178 | 1413 | 1884 |
Incoloy 825 Sheets & Plates Price Per Kg
| Material | Price In INR | Price In USD |
|---|---|---|
| Incoloy 825 | 1,000 to ₹1,200 - Per kg | $15 to $22 - Per kg |
