What Are Stainless Steel 304H Pipes & Tubes?
Global Steel is a leading producer, supplier, stockist, and exporter of Stainless Steel 304H Pipes & Tubes, which are used in a vast range of industrial applications. Our high-quality products are designed to withstand harsh conditions, providing durability, efficiency, and high performance. With years of experience and an unwavering dedication to quality, we have become a name to be trusted in the stainless steel industry.
Table of Content
Stainless Steel 304H Pipes & Tubes, Stainless Steel 304H Pipes & Tubes Manufacturers, Stainless Steel 304H Pipes & Tubes Suppliers, Stainless Steel 304H Pipes & Tubes Stockists, Stainless Steel 304H Pipes & Tubes Exporters
Stainless Steel 304H is a high-carbon variant of the well-known SS 304 grade. The increased carbon content makes it even stronger, and it can be used for high-temperature services. The grade has extensive use in petrochemical, power generation, chemical processing, and heat exchanger applications where high heat and corrosion resistance are necessary. 304H's excellent mechanical properties make it the first choice in applications where high tensile strength and extended service life are required.
At Global Steel, our Stainless Steel 304H Pipes & Tubes are manufactured using high-quality raw materials and state-of-the-art technology. Our manufacturing process is in accordance with international specifications such as ASTM, ASME, and DIN, and each product goes through stringent quality requirements. We offer seamless and welded pipes in various sizes, thicknesses, and specifications to meet the specific requirements of our clients globally.
Stainless Steel 304H Pipes & Tubes Manufacturers in India, Stainless Steel 304H Pipes & Tubes Suppliers in India, Stainless Steel 304H Pipes & Tubes Stockists in India, Stainless Steel 304H Pipes & Tubes Exporters in India
One of the prominent features of our SS 304H Pipes & Tubes is that they have high oxidation and corrosion resistance. These pipes and tubes perform exceptionally well under high-temperature and high-pressure environments, and hence, are highly suitable for demanding industrial applications. Their high formability and weldability also make them simpler to fabricate and install, thereby reducing maintenance time and costs for our customers.
Contact us today to find out our enormous range of Stainless Steel 304H Pipes & Tubes and experience world-class service from a leading industry expert.
Stainless Steel 304H Pipes & Tubes Manufacturers in Mumbai, Stainless Steel 304H Pipes & Tubes Suppliers in Mumbai, Stainless Steel 304H Pipes & Tubes Stockists in Mumbai, Stainless Steel 304H Pipes & Tubes Exporters in Mumbai
Stainless Steel 304H Pipes & Tubes Specifications
| Specifications | ASTM A312, A213, A269, A358 / ASME SA312, SA213, SA269, SA358 |
|---|---|
| Seamless Size | 1 / 8" NB - 24" NB |
| ERW Size | 1 / 8" NB - 36" NB |
| EFW Size | 6" NB - 100" NB |
| Outer Diameter | 6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB |
| Length | Single Random, Double Random & Required Length |
| Schedule | SCH20, SCH30, SCH20, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| Types | Seamless / ERW / EFW / Welded / Fabricated / LSAW Pipes |
| Form | Round Pipes/Tubes, Square Pipes/Tubes, Rectangular Pipe/Tubes, Coiled Tubes, “U” Shape, Pan Cake Coils, Hydraulic Tubes |
Chemical Composition for Stainless Steel 304H Pipes & Tubes
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
|---|---|---|---|---|---|---|---|---|---|
| SS 304H | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 – 20 | - | 8 – 11 | - |
Mechanical properties of Stainless Steel 304H Pipes & Tubes
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Weight Chart Of Stainless Steel 304H Pipes & Tubes
| Nominal Pipe Size (inches) | Outer Diameter (mm) | Wall Thickness (mm) | Weight (kg/m) |
|---|---|---|---|
| 1/2" | 21.3 | 2.0 | 0.82 |
| 3/4" | 26.7 | 2.0 | 1.08 |
| 1" | 33.4 | 2.6 | 1.91 |
| 1 1/4" | 42.2 | 2.6 | 2.45 |
| 1 1/2" | 48.3 | 2.9 | 3.31 |
| 2" | 60.3 | 3.2 | 4.37 |
| 2 1/2" | 76.1 | 3.6 | 6.32 |
| 3" | 88.9 | 4.0 | 8.15 |
| 4" | 114.3 | 4.5 | 12.12 |
Stainless Steel 304H Pipes & Tubes Price Per Kg
| Material | Price In INR | Price In USD |
|---|---|---|
| Stainless Steel 304H | ₹ 200 - Per kg | $ 2.5 - Per kg |
