90 Degree Elbow Buttweld Fitting

Global Steel is a well-known name in manufacturers, suppliers, stockists, exporters and importershigh-performance 90 Degree Elbow Buttweld Fittings. These buttweld fittings make an integral part of pipe networks, creating a 90-degree direction change for efficient flow of fluids and gases. Long-lasting and high-performance, our 90-degree buttweld elbow fittings have a widespread application in industries such as oil & gas, petrochemical, power generation, food processing, and water treatment industries.

Table of Content

90 Degree Elbow Buttweld Fitting Specification Chart
Material of 90 Degree Elbow Buttweld Fitting
Dimensions of 90 Degree Elbow Buttweld Fitting
People Also Search
Application Of Industries

90 Degree Elbow Buttweld Fitting, 90 Degree Elbow Buttweld Fitting Manufacturers, 90 Degree Elbow Buttweld Fitting Suppliers, 90 Degree Elbow Buttweld Fitting Stockists, 90 Degree Elbow Buttweld Fitting Exporters

As one of the most prestigious manufacturers, we ensure that our 90-degree elbow buttweld fittings are designed with high-performance raw materials, imparting them with durability, corrosion resistance, and high strength. All our fittings can be fabricated in a variety of materials such as stainless steel, carbon steel, alloy steel, duplex, super duplex, and high-performance alloys, etc. All our fittings undergo stringent tests for quality in compliance with national and international standards such as ASME, ANSI, ASTM, DIN, and EN, and can therefore, be confidently utilized in critical operations.

Global Steel is a renowned supplier and stockholder with a colossal variety of 90-degree buttweld fittings in its stocks to serve variegated industries' requirements worldwide. Quality and accuracy have facilitated us in supplying ready-to-deliver goods to our customers with almost zero lead times. For any large industrial project, a specific pipe demand, or a custom-fit fitting, our offerings meet specific requirements and dimensions with accuracy. As prominent exporters and importers, we serve worldwide markets, providing high-quality 90-degree elbow buttweld fittings according to international standards of quality.

90 Degree Elbow Buttweld Fitting Manufacturers in India, 90 Degree Elbow Buttweld Fitting Suppliers in India, 90 Degree Elbow Buttweld Fitting Stockists in India, 90 Degree Elbow Buttweld Fitting Exporters in India

90 Degree Elbow Buttweld Fitting Manufacturers in Mumbai, 90 Degree Elbow Buttweld Fitting Suppliers in Mumbai, 90 Degree Elbow Buttweld Fitting Stockists in Mumbai, 90 Degree Elbow Buttweld Fitting Exporters in Mumbai

90 Degree Elbow Buttweld Fitting Specifications

Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175
Specifications	90 Degree Elbow
90 Degree Weld Elbow Pipe Fittings size	Seamless Butt Weld Fittings: 1/2" - 10" Welded Butt Weld Fittings: 1/2" - 48"
90 Degree Pipe Elbow Dimensions	ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10
90 Degree Pipe Elbow Thickness	SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75
90 Degree Reducing Elbow Types	Seamless / ERW / Welded / Fabricated Pipe Fittings
90 Degree Pipe Elbow Type	DN15-DN1200
Connection	Welding
Bending Radius	R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom Pipe Fittings
Size Range	½" NB to 24" NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100)
90 Degree Pipe Elbow Fittings	Angle : 22.5 deg, 30deg, 45 deg, 90 deg, 180 deg, 1.0D, 1.5D, 2.0D, 2.5D, 3D, 4D, 5D, 6D, 7D-40D. Standard: ASME B16.9, ASME B16.28, ASME B16.25, MSS SP-75 DIN2605 JISB2311 JISB2312 JISB2313, BS, GB, ISO
Manufacturing process	Push, Press, Forge, Cast, etc.
90 Degree Reducing Elbow Fittings Test Certificates	EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc
Key markets and industries for 90 Degree Elbow	Bitumen upgraders. Heavy oil refineries. Nuclear power (mostly seamless). Petrochemicals and acids.
Application	Fittings To Connect Pipe & Tubes in Petroleum, Power, Chemical, Construction, Gas, Metallurgy, Shipbuilding etc ASME B16.9 Schedule 10 90 Degree Elbow are an economical alternative for lower-pressure applications. ANSI B16.9 Schedule 40 90 Degree Elbow have a thicker wall for higher-pressure applications.

Material of 45 Degree Elbow

Carbon Steel 90 Degree Elbow	ASTM A234 WPB 90 Degree Elbow ASTM A420 WPL6 90 Degree Reducing Elbow WPHY 42 90 Degree Pipe Elbow WPHY 52 90 Degree Pipe Elbow WPHY 60 90 Degree Reducing Elbow WPHY 65 90 Degree Weld Elbow WPHY 70 90 Degree Pipe Elbow
Stainless Steel 90 Degree Elbow	ASTM A403 WP304 90 Degree Reducing Elbow ASTM A403 WP304L 90 Degree Reducing Elbow ASTM A403 WP316 90 Degree Pipe Elbow ASTM A403 WP316L 90 Degree Reducing Elbow ASTM A403 WP317 90 Degree Reducing Elbow ASTM A403 WP317L 90 Degree Pipe Elbow ASTM A403 WP321 90 Degree Reducing Elbow ASTM A403 WP321H 90 Degree Weld Elbow ASTM A403 WP347 90 Degree Elbow ASTM A403 WP347H 90 Degree Pipe Elbow
Alloy Steel 90 Degree Reducing Elbow	ASTM A234 WP5 90 Degree Weld Elbow ASTM A234 WP9 90 Degree Pipe Elbow ASTM A234 WP11 90 Degree Elbow ASTM A234 WP22 90 Degree Reducing Elbow ASTM A234 WP91 90 Degree Reducing Elbow
Inconel 90 Degree Weld Elbow	Inconel 600 90 Degree Pipe Elbow Inconel 601 90 Degree Reducing Elbow Inconel 625 90 Degree Pipe Elbow Inconel 718 90 Degree Pipe Elbow Inconel x750 90 Degree Elbow
Copper 90 Degree Pipe Elbow	T1, T2, C10100, C10200, C10300, C10400, C10500, C10700, C10800, C10910,C10920, TP1, TP2, C10930, C11000, C11300, C11400, C11500, C11600, C12000,C12200, C12300, TU1, TU2, C12500, C14200, C14420, C14500, C14510, C14520, C14530, C17200, C19200, C21000, C23000, C26000, C27000, C27400, C28000, C33000, C33200, C37000, C44300, C44400, C44500, C60800, C63020, C68700, C70400, C70600, C70620, C71000, C71500, C71520, C71640, etc
Copper Nickel 90 Degree Pipe Elbow	Copper Nickel 90/10 (C70600 ) 90 Degree Reducing Elbow, Cupro Nickel 70/30 (C71500) 90 Degree Elbow, UNS C71640 90 Degree Pipe Elbow
Brass 90 Degree Pipe Elbow	3602 / 2604 / H59 / H62 / etc.
Hastelloy 90 Degree Reducing Elbow	Hastelloy C276 (UNS N10276) 90 Degree Elbow, C22 (UNS N06022) 90 Degree Reducing Elbow, C4 90 Degree Elbow, C2000 90 Degree Weld Elbow, B2 90 Degree Pipe Elbow, B3 90 Degree Elbow, X 90 Degree Pipe Elbow
Monel 90 Degree Reducing Elbow	Monel 400 (UNS No. N04400) 90 Degree Elbow, Monel 500 (UNS No. N05500) 90 Degree Weld Elbow
Alloy 20 90 Degree Pipe Elbow	Carpenter® 20 Alloy 90 Degree Reducing Elbow, Alloy 20Cb-3 90 Degree Pipe Elbow
Aluminium 90 Degree Weld Elbow	5052 /6061/ 6063 / 2017 / 7075 / etc.
Nickel 90 Degree Pipe Elbow	Nickel 200 90 Degree Elbow, Nickel 201 90 Degree Pipe Elbow
Duplex 90 Degree Reducing Elbow	S31803 / S32205 A182 Gr F51 / F52 / F53 / F54 / F55 / F57 / F59 / F60 / F61
Super Duplex 90 Degree Elbow	S32750 / S32760 A182 Gr F51 / F52 / F53 / F54 / F55 / F57 / F59 / F60 / F61
Incoloy 90 Degree Pipe Elbow	Incoloy 800 90 Degree Pipe Elbow, Incoloy 800H 90 Degree Elbow, Incoloy 800HT (UNS N08800) 90 Degree Weld Elbow, Incoloy 825 (UNS N08825) 90 Degree Pipe Elbow
254 Smo 90 Degree Reducing Elbow	SMO 254/6Mo 90 Degree Pipe Elbow, UNS S31254 90 Degree Elbow, DIN 1.4547 90 Degree Weld Elbow
Nimonic 90 Degree Reducing Elbow	Nimonic 75 90 Degree Elbow, Nimonic 80A 90 Degree Elbow, Nimonic 90 90 Degree Pipe Elbow
Other 90 Degree Pipe Elbow material	Tin bronze 90 Degree Weld Elbow, Alumunum bronze 90 Degree Reducing Elbow, Lead bronze 90 Degree Reducing Elbow
Titanium 90 Degree Pipe Elbow	ASTM B381 Titanium Gr. 1 90 Degree Reducing Elbow ASTM B381 Titanium Gr. 2 90 Degree Reducing Elbow ASTM B381 Titanium Gr. 4 90 Degree Weld Elbow ASTM B381 Titanium Gr. 5 90 Degree Elbow ASTM B381 Titanium Gr. 7 90 Degree Pipe Elbow

Dimensions of 45 Degree Elbow

Nom. Pipe Size	Pipe Sched. or No.	Center- to-end Dimen.	Outside Dia.	Inside Dia.	Wall Thick.	Approx. Weight (lb.)
		F	OD	ID	T
STANDARD WEIGHT
1/2	40	5/8	0.840	0.622	0.109	0.1
3/4	40	7/16	1.050	0.824	0.113	0.1
1	40	7/8	1.315	1.049	0.133	0.2
1 1/4	40	1	1.660	1.380	0.140	0.4
1 1/2	40	1 1/8	1.900	1.610	0.145	0.5
2	40	1 3/8	2.375	2.067	0.154	0.9
2 1/2	40	1 3/4	2.875	2.469	0.203	1.5
3	40	2	3.500	3.068	0.216	2.5
3 1/2	40	2 1/4	4.000	3.548	0.226	3.5
4	40	2 1/2	4.500	4.026	0.237	4.8
5	40	3 1/8	5.563	5.047	0.258	7.8
6	40	3 3/4	6.625	6.065	0.280	12
8	40	5	8.625	7.981	0.322	23
10	40	6 1/4	10.750	10.020	0.365	42
12	–	7 1/2	12.750	12.000	0.375	61
14	30	8 3/4	14.000	13.250	0.375	79
16	30	10	16.000	15.250	0.375	103
18	–	11 1/4	18.000	17.250	0.375	132
20	20	12 1/2	20.000	19.250	0.375	160
22	20	13 1/2	22.000	21.250	0.375	195
24	20	15	24.000	23.250	0.375	238
EXTRA STRONG
Nom. Pipe Size	Pipe Sched. or No.	Center- to-end Dimen.	Outside Dia.	Inside Dia.	Wall Thick.	Approx. Weight (lb.)
		F	OD	ID	T
1/2	80	5/8	0.840	0.546	0.147	0.2
3/4	80	7/16	1.050	0.742	0.154	0.3
1	80	7/8	1.315	0.957	0.179	0.4
1 1/4	80	1	1.660	1.278	0.191	0.5
1 1/2	80	1 1/8	1.900	1.500	0.200	0.6
2	80	1 3/8	2.375	1.939	0.218	1.1
2 1/2	80	1 3/4	2.875	2.323	0.276	2.1
3	80	2	3.500	2.900	0.300	3.5
3 1/2	80	2 1/4	4.000	3.364	0.318	4.8
4	80	2 1/2	4.500	3.826	0.337	6.5
5	80	3 1/8	5.563	4.813	0.375	11
6	80	3 3/4	6.625	5.761	0.432	18
8	80	5	8.625	7.625	0.500	35
10	60	6 1/4	10.750	9.750	0.500	56
12	–	7 1/2	12.750	11.750	0.500	80
14	–	8 3/4	14.000	13.000	0.500	100
16	40	10	16.000	15.000	0.500	131
18	–	11 1/4	18.000	17.000	0.500	172
20	30	12 1/2	20.000	19.000	0.500	210
22	30	13 1/2	22.000	21.000	0.500	259
24	–	15	24.000	23.000	0.500	302
