What Are Hastelloy B2 Forged Fittings?
Global Steel manufactured and supplied Hastelloy B2 Forged Fittings are the very best when it comes to performance, longevity, and corrosion resistance in the industrial fitting world. As a top manufacturer, stockist, supplier, and exporter, Global Steel is renowned for supplying high-quality Hastelloy B2 Forged Fittings that meet high standards of performance required by numerous industries around the world.
Table of Content
- Hastelloy B2 Forged Fittings Specification Chart
- Hastelloy B2 Forged Fittings Chemical Composition
- Hastelloy B2 Forged Fittings Mechanical Properties
- Weight Chart Of Hastelloy B2 Forged Fittings
- Hastelloy B2 Forged Fittings Price Per Kg
- People Also Search
- Application Of Industries
- Types Of Hastelloy B2 Forged Fittings
Hastelloy B2 Forged Fittings, Hastelloy B2 Forged Fittings Manufacturers, Hastelloy B2 Forged Fittings Suppliers, Hastelloy B2 Forged Fittings Stockists, Hastelloy B2 Forged Fittings Exporters
Renowned for being extremely versatile, Hastelloy C2000 is one corrosion-resistant alloy that offers the exceptional resistance offered by traditional Hastelloy grades supplemented with superior protection against oxidizing environments through its carefully alloyed composition of nickel, chromium, molybdenum, and copper. Hastelloy B2 Forged Fittings are designed to provide superior performance in aggressive chemical environments like strong oxidizers, reducers, and mixed acid media.
Global Steel Hastelloy B2 Forged Fittings are offered in numerous types and sizes to provide maximum adaptability to varied uses in chemical processing, pharmaceuticals, petrochemicals, power generation, and marine engineering among others. Our forged fittings are thoroughly quality-checked to meet international standards like ASTM B564 and ASME SB564 with uniform mechanical strength, pitting and crevice corrosion resistance, and long service life.
Hastelloy B2 Forged Fittings Manufacturers in India, Hastelloy B2 Forged Fittings Suppliers in India, Hastelloy B2 Forged Fittings Stockists in India, Hastelloy B2 Forged Fittings Exporters in India
We stock an extensive selection of Hastelloy B2 Forged Fittings in many configurations, including socket welds, threaded elbows, tees, couplings, and unions, to name just a few, ready to ship globally. Our skilled technical staff offers custom solutions to suit individual client needs with utmost attention to detail and care in handling each order. Our attention to innovation, technical performance, and dependability has made Global Steel the first name to come to mind when it comes to corrosion-resistant forged fittings.
Global Steel ensures that each Hastelloy C2000 Forged Fitting manufactured in our state-of-the-art plants meets the finest standards of metallurgy and accuracy through its rigorous quality controls. In addition, we have an extensive inventory for immediate needs with options for timely deliveries across the globe.
Hastelloy B2 Forged Fittings Manufacturers in Mumbai, Hastelloy B2 Forged Fittings Suppliers in Mumbai, Hastelloy B2 Forged Fittings Stockists in Mumbai, Hastelloy B2 Forged Fittings Exporters in Mumbai
Hastelloy B2 Forged Fittings Specifications
| Standard | ASTM B564 / ASME SB564 |
|---|---|
| Dimensions | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Type | Socketweld Fittings, Screwed-Threaded Fittings |
| Class | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
Chemical Composition for Hastelloy B2 Forged Fittings
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
|---|---|---|---|---|---|---|---|---|
| Hastelloy B2 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
Mechanical properties of Hastelloy B2 Forged Fittings
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Weight Chart Of Hastelloy B2 Forged Fittings
| Size (NB) | Socket Weld Elbow (kg) | Threaded Elbow (kg) | Tee (kg) | Coupling (kg) | Cap (kg) |
|---|---|---|---|---|---|
| 1/8" | 0.04 | 0.03 | 0.06 | 0.04 | 0.02 |
| 1/4" | 0.07 | 0.06 | 0.10 | 0.07 | 0.04 |
| 3/8" | 0.10 | 0.09 | 0.14 | 0.09 | 0.06 |
| 1/2" | 0.16 | 0.14 | 0.22 | 0.15 | 0.09 |
| 3/4" | 0.32 | 0.28 | 0.44 | 0.30 | 0.17 |
| 1" | 0.56 | 0.50 | 0.77 | 0.55 | 0.30 |
| 1 1/4" | 0.84 | 0.75 | 1.20 | 0.85 | 0.48 |
| 1 1/2" | 1.26 | 1.10 | 1.80 | 1.25 | 0.70 |
| 2" | 2.40 | 2.10 | 3.40 | 2.30 | 1.20 |
| 2 1/2" | 3.90 | 3.50 | 5.60 | 3.80 | 2.00 |
| 3" | 5.50 | 4.90 | 8.20 | 5.40 | 2.80 |
| 4" | 9.60 | 8.50 | 14.00 | 9.20 | 4.80 |
Hastelloy B2 Forged Fittings Price Per Kg
| Material | Price In INR | Price In USD |
|---|---|---|
| Hastelloy B2 | ₹ 9000 - Per kg | $112.5 - Per kg |
People Also Search
Hastelloy B2 Forged Fittings, alloy B2 socket weld fittings price list, hastelloy B2 socket weld fittings supplier in india, hastelloy alloy B2 threaded street elbow, hastelloy alloy B2 threaded elbow supplier in mumbai, hastelloy B2 socket weld elbow price list in india, hastelloy alloy B2 forged threaded fittings manufacturer in mumbai, hastelloy B2 forged reducing coupling, Hastelloy B2 Forged Fittings manufacturer, hastelloy alloy B2 round head plug, hastelloy alloy B2 forged fittings price list, hastelloy B2 90 deg socket weld elbow supplier, Hastelloy B2 Forged Fittings suppliers, hastelloy B2 socket weld fittings catalog, hastelloy alloy B2 threaded hex head plug, hastelloy B2 forged bull plug, B2 hastelloy forged price list, hastelloy B2 socket weld fittings supplier, hastelloy 3d elbow grade B2 price list, hastelloy B2 forged reducing elbow supplier, Hastelloy B2 Forged Fittings manufacturers in india
Application Of Industries
Power Plants Industry
Aerospace Industry
Refineries Industry
Oil & Gas Industry
Sugar Industry
Chemical Industry
Petrochemical Industry
